- Ürün Kodu : CH2152
- Ürün Adı : Caliper Overhaul Seal Kit
- Ürün Ölçüsü/Ağırlığı : 0,200 gr
İçindekiler
| Sıra | Görsel | Kod | Adı | Boyut |
| 1 |
|
CH2620 | Cover Gasket | 0,010 gr |
| 2 |
|
CH2617 | Shaft Inner Seal Ø52/Ø39 mm | 0,010 gr |
| 3 |
|
CH2619 | Seal Cover Ø62 x Ø42 x 6 mm | 0,015 gr |
| 4 |
|
CH2618 | Shaft Outer Seal Ø57/Ø40 mm | 0,010 gr |
| 5 |
|
CH2621 | Dust Plug | 0,002 gr |
| 6 |
|
CH2622 | O-ring | 0,001 gr |
| 7 |
|
CH2541 | Steel Cap Ø37 x 11 mm | 0,020 gr |
| 8 |
|
CH2549 | Steel Cap Ø42 x 45 mm | 0,095 gr |
| 9 |
|
CH2586 | Tappet Dust Excluder | 0,020 gr |
| 10 |
|
CH2596 | Guide Pin Dust Excluder | 0,010 gr |
Not: İlgili parçalardan bazı setlerde bir kaç adet bulunabilir.
| Ad | Değer |
| MRT | SJ4061 |
| NSSN | 69029770 |
